8DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts

Basic Information
Place of Origin: JAPAN
Brand Name: NPR
Model Number: 8DC8
Minimum Order Quantity: 1 SET
Price: usd+148+SET
Packaging Details: CARTON
Delivery Time: 2-5days
Payment Terms: T/T
Supply Ability: 100 SETS
Detail Information
Type:: Piston Ring Brand Name :: NPR
Place Of Origin:: JAPAN Condition:: New, 100%new
OEM No:: ME062022 ME062216 NPR Catalog Code:: SDM31028ZZ / YDM31028ZZ
Reference:: ME062022 ME062216 Make :: MITSUBISHI
Engine Model:: 8DC6 8DC81(NEW) Cyl No. :: V8
SET/CYL:: SET/CYL Delivery Time:: 2-5days
High Light:

8DC8 Piston Ring

,

ME062022 Piston Ring

,

ME062216 Piston Ring


Product Description

8DC8 Piston Ring ME062022 ME062216 Suitable For Mitsubishi Engine Parts​







Piston Size(mm)
d1(D) h1(B) a1(T)
1st 135.0 3.306 5.4
2nd 135.0 3.0 5.5
Oil 135.0 6.0 5.5







8DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 08DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 18DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 28DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 38DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 48DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 58DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 68DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 7





“NPR PISTON RING SET” Fitting Instruction

I. Install piston rings in the following order:

1,Thoroughly clean ring grooves of piston.

2,Fit the oil control -followed by compression rings in ascending order,into the ring grooves using a ring tool.

3, Take care to fit the rings with marked faces upward and toward top of the piston.

II.Confirmation that rings are fitted correctly:

1,Make sure rings can be moved freely - without jamming-in the piston grooves.

2,Make sure each ring gap is not positioned in line with piston pin axis or thrust

III.Installation of piston fitted with rings:

Always use an installation tool when inserting into cylinder.

Special instruction for fitting NPR NIFFLEX oil ring

1, Fit the expander of NIFFLEX oil ring into the ring groove by hand and ensure the ends butting together as shown in the illustration.

2,Hold with your thumb the expander at its butt ends. Fit the upper rail on to the expander with its gap approx.45° to the left,and the lower rail approx.45° to the right to the ends of expander.









8DC8 Piston Ring ME062022 ME062216 For Mitsubishi Engine Parts 8
