F21C NPR Piston Rings 13011-3310A 13019-1730A For HINO Engine Parts

Detail Information
Type:: Piston Ring Brand Name :: NPR
Place Of Origin:: JAPAN Condition:: New, 100%new
OEM No:: 13011-3310A 13019-1730A(cyl) NPR Alog Code:: YJH20076ZY
Reference:: 13011-3310A 13019-1730A(cyl) Make :: HINO
Engine Model:: F21C Cyl No. :: V8
SET/CYL:: CYL Delivery Time:: 2-5days
Highlight:

F21C NPR Piston Rings

,

13011-3310A NPR Piston Rings

,

13019-1730A NPR Piston Rings


Product Description

F21C Piston Ring 13011-3310A 13019-1730A(cyl) Suitable For HINO Engine Parts





Piston Size(mm)
d1(D) h1(B) a1(T)
1st 150.0 3.306 5.5
2nd 150.0 3.0 5.8
3rd 150.0 3.0 5.8
Oil 150.0 4.0 4.65





F21C NPR Piston Rings 13011-3310A 13019-1730A For HINO Engine Parts 0F21C NPR Piston Rings 13011-3310A 13019-1730A For HINO Engine Parts 1F21C NPR Piston Rings 13011-3310A 13019-1730A For HINO Engine Parts 2F21C NPR Piston Rings 13011-3310A 13019-1730A For HINO Engine Parts 3F21C NPR Piston Rings 13011-3310A 13019-1730A For HINO Engine Parts 4F21C NPR Piston Rings 13011-3310A 13019-1730A For HINO Engine Parts 5





“NPR PISTON RING SET” Fitting Instruction

I. Install piston rings in the following order:

1,Thoroughly clean ring grooves of piston.

2,Fit the oil control -followed by compression rings in ascending order,into the ring grooves using a ring tool.

3, Take care to fit the rings with marked faces upward and toward top of the piston.

II.Confirmation that rings are fitted correctly:

1,Make sure rings can be moved freely - without jamming-in the piston grooves.

2,Make sure each ring gap is not positioned in line with piston pin axis or thrust

III.Installation of piston fitted with rings:

Always use an installation tool when inserting into cylinder.

Special instruction for fitting NPR NIFFLEX oil ring

1, Fit the expander of NIFFLEX oil ring into the ring groove by hand and ensure the ends butting together as shown in the illustration.

2,Hold with your thumb the expander at its butt ends. Fit the upper rail on to the expander with its gap approx.45° to the left,and the lower rail approx.45° to the right to the ends of expander.









F21C NPR Piston Rings 13011-3310A 13019-1730A For HINO Engine Parts 6
